Cell Orientation

108(6×18)

Junction Box

IP68

Output Cable

4mm², ±1200mm

length can be customized

Glass

Single glass, 3.2mm coated tempered glass

Frame

Anodized aluminum alloy frame

Weight

20.8kg

Dimensions

1722×1134×30mm

Packaging

36pcs per pallet/216pcs per 20' GP/936pcs per 40 'HC

Operating Temperature

-40℃~+85℃

Power Output Tolerance

0~3%

Maximum System Voltage

DC1500V(IEC/UL)

Maximum Series Fuse Rating

25A

Nominal Operating Cell Temperature

45±2℃

Protection Class

Class Ⅱ
